The Scroll Renderer recipe provides a framework for scroll-linked WebGL effects on arbitrary DOM elements. It comes with a couple of different classes to link to WebGL drawables: ScrollScene forms the base layer, linking arbitrary DOM elements to WebGL effects, and ScrollImage links individual images to scroll-reactive WebGL effects.

It controls a single WebGL context and render loop, allowing for complex layered effects with multiple scroll-linked elements without the overhead of multiple contexts or loops.

In this demo, we've linked the background shader to a ScrollScene anchored to a fixed full-viewport element, and each of the four foreground images to individual ScrollImages. The scroll position of each image is tracked separately via onBeforeRender, allowing for independent parallax and distortion effects.

Hit the "WEBGL" toggle, top-left to switch between WebGL and DOM views so you can see how the image positioning informs the shader layout.

01 · How to

Example.

The WebGL program for each image is a simple mesh shader with transform feedback, allowing the vertex shader to update the position and velocity of each vertex on the fly. Scroll-linked distortion and mouse interaction are added as uniform offsets to the vertex positions, and a noise function is used to create an organic erosion effect around the edges.

const renderer = new ScrollRenderer()
document.body.appendChild(renderer.canvas)

document.querySelectorAll('.blade-img').forEach((imgEl) => {
  const drawable = new Drawable(gl)
  const scene = new ScrollImage({ gl, element: imgEl, scene: drawable })

  const program = new Program(gl, {
    vertex: imageVert,
    fragment: imageFrag,
    uniforms: { ...scene.uniforms },
    transparent: true,
  })

  new Mesh(gl, {
    geometry: new Plane(gl, { widthSegments: 24, heightSegments: 18 }),
    program,
  }).setParent(drawable)

  renderer.addScene(scene)
})

renderer.playing = true

02 · ScrollRenderer

One canvas. Many scenes.

ScrollRenderer manages a single fixed <canvas> and one requestAnimationFrame loop for all registered scenes. Each scene is scissor-tested to its DOM element's exact pixel bounds, so multiple WebGL effects share one context with no overdraw outside their element.

Scenes outside the viewport are skipped automatically via IntersectionObserver. The aurora background is a ScrollScene anchored to a fixed full-viewport element. Which shows off the fact that scroll renderer just knows where to draw things.

03 · Uniforms

Wired up automatically.

ScrollScene maintains a set of uniforms that are updated every frame and ready to spread directly into your Program: u_time (elapsed), u_resolution (element size in physical pixels), and u_origin (element position in both pixel and NDC space). ScrollImage adds u_image and u_imageSize for the GPU-uploaded texture.

Custom uniforms - like the scroll velocity and mouse position used for the cloth simulation here - are created with Uniform and merged in alongside them. Update .value each frame inside onBeforeRender and the program picks up the change automatically.

const u_mouse = new Uniform({
  name: 'u_mouse', value: [0.5, 0.5], kind: 'float_vec2',
})

const program = new Program(gl, {
  uniforms: {
    ...scene.uniforms, // u_time, u_resolution, u_origin,
                       // u_image, u_imageSize
    u_mouse,
  },
})

scene.onBeforeRender = () => {
  u_mouse.value = mouse
}

04 · Another image

We had a fourth image.

It needed to go somewhere. Here it is. It looks great. The cloth effect works on it too.

There's no technical insight here. We just didn't want to waste it.
